Hardness Testing Accessories

Indenters

According to the latest standards, there are changes to both Rockwell and Brinell scales. The test method for Rockwell testing (ASTM E-18-08a) only allows the use of tungsten carbide ball indenters.

AMETEK makes a variety of Newage indenters and indenter accessories. We recommend that you contact us, for assistance in specifying and ordering an indenter for your Rockwell, Brinell or Microhardness application.

Click on one of the menus below to see the full range of indenters.

BUY NOW! Our hardness testing accessories are also available for easy and safe online purchase on our webshop store.ametekstc.com

Rockwell Diamond Indenters +
- Part no. 8103-07 - BUY NOW!

  Indenter, diamond, C & A scales, with certificate.
- Part no. 8105-07 - BUY NOW!

  Indenter, diamond, C, N & A scales, with certificate
- Part no. 8109-07 - BUY NOW!

  Indenter, diamond, N scale, with certificate.
- Part- no. 8110-07 - BUY NOW!

  Indenter, diamond, C scale, with certificate.
- Part no. AT/5103-07

  Indenter, diamond, C & A scales, with certificate.
- Part no. AT/5106-07

  Indenter, diamond, N scale, with certificate, tapered for use with shroud 5404.
- Part no. AT/5107-07

  Indenter, diamond, C, A and D scales, with certificate, tapered for use with shroud 5404.
- Part no. AT/5109-07

  Indenter, diamond, N scale, superficial, with certificate.
- Part no. AT/5110-07

  Indenter, diamond, C scale, with certificate.
- Part no. NI-SP3

  Indenter, diamond, short form type.

Rockwell Tungsten Carbide Ball Indenters +
- Part no. 8111W07 - BUY NOW!

  Indenter, tungsten carbide, 1/16", with certificate.
- Part no. 8112W07 - BUY NOW!

  Indenter, tungsten carbide, 1/8", with certificate.
- Part no. 8113W07 - BUY NOW!

  Indenter, tungsten carbide, 1/4", with certificate.
- Part no. 8114SW07

  Indenter, tungsten carbide, 1/2", with certificate.
- Part no. AT/5111W07

  Indenter, tungsten carbide, 1/16", B, F, G and T scales, with certificate.
- Part no. AT/5112W07

  Indenter, tungsten carbide, 1/8", E, H, K and W scales, with certificate.
- Part no. AT/5113W07

  Indenter, tungsten carbide, 1/4", L, M, P and X scales, with certificate.
- Part no. NI-SP4

  Indenter, tungsten carbide, 1/16", short form type.
- Part no. 8115W

  Indenter, tungsten carbide, 2.5mm, with certificate (requires optional Brinell conversion package).
- Part no. 8116W

  Indenter, tungsten carbide, 5mm, with certificate (requires optional Brinell conversion package).
- Part no. AT/5116W

  Ball component, tungsten carbide, 1/16", with certificate
- Part no. AT/5117W - BUY NOW!

  Ball component, tungsten carbide, 1/8", with certificate
- Part no. AT/5121W - BUY NOW!

  Ball component, tungsten carbide, 1/4", with certificate.
- Part no. BR/3155

  Ball only, tungsten carbide, 5mm.
- Part no. HB/3006B

  Ball only, tungsten carbide, 2.5mm.

Rockwell Steel Ball Indenters +
- Part no. 8111S - BUY NOW!

  Indenter, steel, 1/16", with certificate, with 50 extra balls.
- Part no. 8112S

  Indenter, steel, 1/8", with certificate, with 10 extra balls.
- Part no. 8113S

  Indenter, steel, 1/4".
- Part no. 8114S

  Indenter, steel 1/2".
- Part no. AT/5111S

  Indenter, steel, 1/16", with 50 extra balls.
- Part no. AT/5112S

  Indenter, steel, 1/8", with 10 extra balls.
- Part no. AT/5116S - BUY NOW!

  Ball component, steel, 1/16", 50 balls.
- Part no. AT/5117S - BUY NOW!

  Ball component, steel, 1/8", 10 balls
- Part no. AT/5121S - BUY NOW!

  Ball component, steel, 1/4", 10 balls

Brinell Carbide Indenters +
- Part no. 81HE-08C

  Indenter, tungsten carbide ball, 10mm, with certificate.
- Part no. BR/3030

  Indenter, tungsten carbide ball, 10mm, “Slim-style”, with certificate.
- Part no. BR/3031

  Indenter, tungsten carbide ball, 5mm, “Slim-style”, with certificate.
- Part no. BR/3152

  Ball only, tungsten carbide, 10mm.
- Part no. BR/3155

  Ball only, tungsten carbide, 5mm.
- Part no. HB/3006

  Indenter, tungsten carbide ball, 2.5mm, with certificate.
- Part no. HB/3030

  Indenter, tungsten carbide ball, 10mm, with certificate.
- Part no. HB/3031

  Indenter, tungsten carbide ball, 5mm, with certificate.
- Part no. HB/3006B

  Ball only, tungsten carbide, 2.5mm.
- Part no. HB/301

  Indenter extension, 1.5” (38mm).
- Part no. HB/110

  Indenter ball holder, 10mm.
- Part no. HB/109

  Indenter cap, 10mm.

Microhardness Indenters +
- Part no. MS-311

  Indenter, Vickers.
- Part no. MS-312

  Indenter, Knoop.
